Monel 400 is an alloy that has numerous features and benefits which are required in industrial applications. It is a combination of Nickel and Copper. It has excellent strength and corrosion resistance properties. Monel 400 is extensively suitable for piping applications because of its anti-corrosive properties, which offer resistance to both seawaters as well as steam.
Seamac Piping Solutions Inc. is a leading manufacturer and exporter of a wide range of Monel 400 Sheet Plate. These Plates are demanded by various industries to complete multiple operations. We are fabricating the best quality Monel 400 Sheet Plate with numerous beneficial properties like high mechanical strength, good flexibility, excellent weldability, high toughness, and high corrosion resistance. These Plates provide resistance to pitting as well as crevice corrosion cracking in under extreme conditions.
Seamac Piping Solutions Inc. carries a wide range of Monel 400 sheets and plates in a variety of lengths, ODs, IDs, size and wall thicknesses to meet your project’s needs—including sheets and plates in dimension as per ASTM and weight-kg. per mtr. weight & thickness of 400 Monel sheets plates .
We are using the highest quality Monel 400 alloy to produce these Plates. This makes us able to supply the most excellent Monel 400 Sheet Plate. Our high-grade Monel 400 Sheet Plate are suitable for both acidic and alkaline environments. We have a highly qualified professional team that manufactures these Monel 400 Plates by using supreme material, latest machinery, and advanced technology.
Seamac Piping Solutions Inc. has a client base all over the globe, and hence we are following all national and international quality standards to deliver perfectly suitable Plates. Our precise Monel 400 Sheet Plate are available in different sizes, shapes, thicknesses, and materials. We ensure to offer Monel 400 Sheet Plate with higher efficiency, long service life, high dimensional accuracy, high strength, and durability. We make sure that every Plate is undergone through strict quality tests under the supervision of our experienced quality team.
Monel 400 Sheets and Plates Specifications
Specification : ASTM B127 / ASME SB127
Dimension Standard : JIS, AISI, ASTM, GB, DIN, EN, etc
Monel Sheet : thickness range from .008" to .0125"
Monel Plate : thickness ranges from .0125" to 5.00"
Size : 15NB to 150NB In
Tempers : Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard
Hardness: Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Form: Coils, Foils, Rolls, Plain Sheet, Strip, Flats, Blank (Circle), Ring (Flange) etc.
ASME SB127 Monel 400 Sheets and Plates Equivalent Grades
| STANDARD |
UNS |
WNR. |
AFNOR |
EN |
JIS |
BS |
GOST |
| Monel 400 |
N04400 |
2.4360 |
NU-30M |
NiCu30Fe |
NW 4400 |
NA 13 |
МНЖМц 28-2,5-1,5 |
In our highly equipped development unit, we are the latest machinery and equipment which we are using to deliver high-quality Plates. We have supreme storage and warehousing to store ready stock of Plates, which helps to complete the urgent requirements of our clients. Seamac Piping Solutions Inc. is also focusing on packaging and shipping of products to ensure safe and damage-free doorstep service within the decided time.
Monel 400 Sheets and Plates Types
Alloy 400 Perforated Sheets
ASTM B127 Monel 400 Perforated Sheets
UNS N04400 Perforated Sheets
Monel 2.4360 Perforated Sheets
Monel® 400 Chequered Plates
ASTM B127 Alloy 400 Chequered Plates
UNS N04400 Chequered Plates
Monel 2.4360 Chequered Plates
Monel 400 Shim Sheets
ASTM B127 Monel 400 Shim Sheets
UNS N04400 Shim Sheets
Alloy 2.4360 Shim Sheets
Monel 400 Coils
ASTM B127 Alloy 400 Coils
UNS N04400 Coils
Monel 2.4360 Coils
Monel 400 Sheets Sizes in Stock:
All Sheets and Plates is manufactured and tested / inspected to the relevant standards including ASTM, ASME and API etc.
| Monel Gauge Width and Length |
Weight Lbs. per Sq. Ft. |
Estimated Weight per Sheet |
| 7 ga. (.1874") x 48 x 120 |
7.871 |
314.8 |
| 10 ga. (.135") x 48 x 120 |
5.670 |
226.8 |
| 11 ga. (.120") x 36 x 120 |
5.040 |
151.2 |
| 11 ga. (.120") x 48 x 96 |
5.040 |
161.3 |
| 11 ga. (.120") x 48 x 120 |
5.040 |
201.6 |
| 11 ga. (.120") x 48 x 144 |
5.040 |
241.9 |
| 11 ga. (.120") x 60 x 96 |
5.040 |
252.0 |
| 12 ga. (.105") x 36 x 120 |
4.410 |
132.3 |
| 12 ga. (.105") x 48 x 120 |
4.410 |
176.4 |
| 12 ga. (.105") x 60 x 120 |
4.410 |
220.5 |
| 14 ga. (.075") x 36 x 120 |
3.150 |
94.50 |
| 14 ga. (.075") x 48 x 120 |
3.150 |
126.0 |
| 16 ga. (.060") x 36 x 120 |
2.520 |
75.60 |
| 16 ga. (.060") x 48 x 96 |
2.520 |
80.64 |
| 16 ga. (.060") x 48 x 120 |
2.520 |
100.8 |
| 16 ga. (.060") x 60 x 120 |
2.520 |
126.0 |
| 18 ga. (.048") x 36 x 120 |
2.016 |
60.48 |
| 18 ga. (.048") x 48 x 120 |
2.016 |
80.64 |
| 20 ga. (.036") x 36 x 120 |
1.512 |
45.36 |
| 20 ga. (.036") x 48 x 120 |
1.512 |
60.48 |
| 22 ga. (.030") x 36 x 120 |
1.260 |
37.80 |
| 22 ga. (.030") x 48 x 96 |
1.260 |
40.32 |
| 22 ga. (.030") x 48 x 120 |
1.260 |
50.40 |
| 24 ga. (.024") x 36 x 120 |
1.008 |
30.24 |
| 24 ga. (.024") x 48 x 120 |
1.008 |
40.32 |
| 26 ga. (.018") x 36 x 120 |
.7560 |
22.68 |
| 26 ga. (.018") x 48 x 120 |
.7560 |
30.24 |
| 28 ga. (.015") x 36 x 120 |
.6300 |
18.90 |
Chemical Composition of Monel 400 Sheets and Plates
| Grade |
Ni |
C |
Al |
Mn |
Si |
Fe |
Cu |
S |
| Monel 400 |
63.0 min |
0.3 max |
0.50 max |
2.0 max |
0.5 max |
1.0 - 2.5 |
28.0 - 34.0 |
0.02 max |
Mechanical Properties of Alloy 400 Sheets and Plates
| Density |
Melting Point |
Yield Strength (0.2%Offset) |
Tensile Strength |
Elongation |
| 8.8 g/cm3 |
1350 °C (2460 °F) |
Psi – 35,000 , MPa – 240 |
Psi – 80,000 , MPa – 550 |
40 % |
Monel 400 Sheets and Plates Application Industries
- Chemical Industry
- Petrochemical industry
- Marine & Power Transmission industry
- Power plants
- Energy industries
- Furniture
- Pharmaceutical processing industry
- Modern architecture
- Home appliances
- Water waste projects
- Synthetic fiber
- Heat exchanger
- Fluid piping
- Dairy and food processing
